Product Key Features
1.High-Performance Lithium Power: Utilizes a large-capacity 80V/110Ah LiFePO4 battery, delivering enduring power and supporting fast charging to meet the demands of intensive multi-shift operations. The battery boasts a long cycle life and high energy density, effectively increasing runtime per charge.
2.Robust Operational Performance: Equipped with a powerful 6kW AC drive motor and a 6kW AC lift motor, it achieves a high full-load travel speed of 12 km/h and a laden gradeability of 15%, with a lifting speed of 240mm/s, significantly outperforming peers in efficiency.
3.Intelligent Control Hub: Features an advanced intelligent control and display system with high integration. It monitors real-time vehicle status, battery level, efficiency statistics, and diagnostic information. This system lays the groundwork for future upgrades to telematics terminals (like the IZD series), facilitating digital fleet management.
4.Front-Wheel Drive & Superior Ground Clearance: The innovative front-wheel drive design, combined with a generous 65mm underclearance at the frame and 90mm at the mast, provides outstanding ground adaptability and traversing capability, easily handling uneven surfaces like dock plates and thresholds.
5.Safety & Stability Design:
Large mast tilt angles (6掳 forward / 12掳 rearward) ensure greater load stability during handling.
85mm free lift height facilitates stacking operations in low-overhead spaces.
High-standard safety features, typically including emergency power-off, overload protection, etc., ensure operational safety.
6.Precise & Agile Handling: With a compact turning radius of 1350mm and an overall length of just 1575mm (without forks), it offers superior maneuverability in narrow aisles. The 800mm front tread enhances lateral stability during operations.
Comparative Advantages
Vs. Standard Electric Forklifts of Same Capacity
Power & Efficiency: The dual 6kW AC motor system provides power output that far exceeds most counterparts, ensuring performance advantages on slopes and during high-speed travel, directly boosting material throughput.
Traversability & Adaptability: The front-wheel drive and high ground clearance design offer better negotiation of uneven surfaces or obstacles compared to traditional rear-drive or low-clearance models.
Intelligence Level: The intelligent control hub not only provides basic info but also enables potential for advanced telematics management, a feature lacking in many standard electric forklifts.
Vs. Internal Combustion & Lead-Acid Forklifts
路 Operating Cost: High energy conversion efficiency of lithium batteries and zero daily maintenance result in a significantly lower total cost of ownership compared to ICE and lead-acid counterparts.
路 Eco-friendliness & Operator Experience: Zero emissions and low noise allow for operation both indoors and outdoors, improving the working environment. Opportunity charging eliminates efficiency losses associated with long charging cycles of lead-acid batteries.
Pain Point Solutions
Pain Point 1: Steep ramps in the warehouse cause standard electric forklifts to struggle, hampering efficiency.
Solution 1: Its high laden gradeability of 15% enables it to easily handle various slopes, ensuring smooth logistics flow.
Pain Point 2: Narrow aisles make turning and maneuvering difficult, limiting space utilization.
Solution 2: The combination of the three-wheel design and a small 1350mm turning radius provides exceptional agility in tight spaces, helping to maximize storage density.
Pain Point 3: Low intelligence level of traditional forklifts makes fleet management challenging.
Solution 3: The intelligent control hub serves as a data interface, providing core support for vehicle tracking, working hour analysis, efficiency evaluation, and preventive maintenance, making fleet management transparent and efficient.
Pain Point 4: Complex operating environments with ground obstacles risk undercarriage damage.
Solution 4: The optimized high ground clearance (65mm at frame, 90mm at mast) effectively reduces the risk of undercarriage impacts in challenging conditions, enhancing the vehicle's adaptability.
