Key Features
Powerful and Reliable Performance – Equipped with the Quanchai/Xinchai series 490BGP-262 diesel engine, 2540cc displacement, four cylinders with 90×100mm bore and stroke, delivering 40kW at 2650rpm and 148N·m at 1800rpm. Outstanding cold start capability, low failure rate, reduced overall energy consumption, and extended service life. With 20% gradeability and 18.5km/h full-load travel speed, it confidently handles outdoor ramps and challenging terrain.
Compact Maneuverability – With a minimum turning radius of only 1960mm, minimum right-angle aisle width of 1810mm, and overall width of just 1090mm, the HH15(Z) navigates narrow warehouse aisles and container interiors with exceptional ease. Minimal repositioning required—productivity enhanced in tight spaces.
Excellent Visibility and Safe Control – Wide-view mast design complemented by wide-angle rearview mirrors minimizes blind spots. Fork spacing adjustable from 240mm to 1040mm accommodates various pallet sizes. Mast tilt of 6° forward and 12° backward enables precise loading and unloading.
Operator Comfort for Extended Shifts – Adjustable steering wheel allows operators to find their optimal driving position. Suspended cabin and shock absorption system effectively filter road vibrations. High-quality steering wheel paired with comfortable seating keeps operators focused and efficient through long workdays.
Durable Design with Low Maintenance Costs – Reinforced integrated frame structure delivers superior impact resistance. Hydraulic transmission ensures smooth operation. Modular electrical box with high protection rating simplifies servicing. Long-lasting wearing parts minimize downtime and reduce total cost of ownership.
Competitive Advantages vs. Industry Peers
1. Superior Compact Agility – With a 1960mm minimum turning radius and 1090mm width, the HH15(Z) outperforms competing 1.5-ton diesel forklifts in narrow spaces. By comparison, typical 2-ton forklifts have turning radii above 2300mm—the HH15(Z) achieves approximately 15% higher productivity in confined environments.
2. Balanced Power and Efficiency – The 490BGP-262 engine delivers 2540cc displacement and 40kW power, greater displacement than 2-ton forklifts (typically ~2369cc), providing stronger low-end torque for better heavy-start performance. The load-sensing hydraulic system enables full-load lifting at idle, reducing fuel consumption by approximately 8%.
3. Optimal Self-Weight, High Payload Efficiency – At just 3500kg, the HH15(Z) is approximately 200kg lighter than 2-ton counterparts, reducing ground pressure while maintaining its 1500kg rated capacity—delivering industry-leading payload-to-weight efficiency.
4. Ergonomic Operator Design – Adjustable steering wheel, wide-view mast, and reduced noise and emissions keep drivers comfortable during extended shifts.
5. Durable Componentry – Premium Chinese brand wear-resistant tires and Japan-sourced hydraulic pumps and valves reduce engine and hydraulic system failure rates, extending service intervals and lowering overall operating costs.
Solutions to User Pain Points
Pain Point: Narrow warehouse aisles make maneuvering difficult → Minimum turning radius of just 1960mm and right-angle aisle width of 1810mm ensure easy navigation in tight spaces.
Pain Point: Insufficient power for outdoor ramps → 20% gradeability and 148N·m torque output provide confident climbing capability—no stalling under heavy loads on slopes.
Pain Point: High fuel consumption driving up operating costs → Load-sensing hydraulic system with idle lifting technology reduces fuel consumption by approximately 8%, delivering substantial annual savings.
Pain Point: Operator fatigue reducing productivity → Adjustable steering wheel, shock-absorbing seat, and low noise emissions keep operators comfortable and efficient throughout long shifts.
Pain Point: Complex maintenance leads to excessive downtime → Modular electrical box design and reinforced frame structure allow quick, straightforward servicing.
