HI6600ES
Huahe
Huahe Heavy Industries Co., Ltd., leveraging its integrated industrial and trading supply chain advantages, offers flexible energy solutions to traders and end-users.
Huahe has developed and produced this Hi6600ES product: a high-power silent variable-frequency generator. It has the following core features:
1. Open customization services for the entire series to meet diverse needs in households, businesses, and professional fields.
2. Ultra-low noise of 90 dB.
3. 42 kg body weight capacity.
4. Safeguarding equipment safety with ≤3% pure current.
5. Flexible emergency response with dual startup systems.
Huahe is committed to the research and production of generators ranging from 1 to 10 kw for export. If you have any needs in the generator market, you can directly contact us. Huahuo provides ODM/OEM services, with the ultimate goal of satisfying customers.
| Model | Hi6500ES | |
| Generator | Type |
Inverter Generator |
| Frequency/Hz | 50Hz/60Hz | |
| Rated Voltage/V | 110V/230V/380V | |
| Rated Power Output/W | 5000/6000 | |
| Max Power Output/W | 5500/6500 | |
| Power Facter | 1.0 | |
| Waveform Distortion Rate/% | ≦3% | |
| Noise Level (at 7m)/dB | 70-75(100% Load) | |
| Overload Protection AC | Frequency converter overcurrent protection program control | |
| Operating Altitude | ≦1000m | |
| Engine | Model |
HH172F |
| Type | Single cylinder,4-stroke,Forced air cooling,Overload valve | |
| Displacement/cc | 240cc | |
| Fuel Type | Unleaded Gasoline | |
| Fuel Tank Capacity/L | 12 | |
| Engine oil volume/L | 0.6 | |
| Overall Dimensions |
Ignition plug model | F7RTC/FTTC |
| Starting System | Manual start/Electric start | |
| Dimension(L*W*H)/mm | 560*420*450 | |
| Net weight/kg |
42 | |
(Configurations such as frequency, voltage and panel can be customized according to your needs)
Core Product Features
Library-level Noise Reduction Technology:≤90dB ultra-low noise (7-meter distance), 15% lower than industry counterparts (compared to conventional 105dB models) - ≤3% waveform distortion rate, safe for driving precision electronic products (laptops, drone charging stations)
Flexible Dual Startup System for Emergency Situations:Dual-mode design of electric start + manual start, unafraid of sudden scenarios such as battery depletion - Miniature body size of 560×420×450mm, lightweight structure of 42kg, can be quickly deployed by one person
Efficient and Energy-Efficient Power Core:HH172F single-cylinder four-stroke engine (240cc), forced air cooling + overload valve dual protection - 5L fuel tank + 0.6L ultra-low oil consumption, 20% improvement in range compared to models with the same 6L fuel tank ---
Product Feature Comparison
| Feature | Hi6600ES | Conventional 5kW Generator |
| Noise Control | ≤90dB (7-meter) | 100-105dB |
| Startup Reliability | Dual backup of electric start + manual start | Only manual start |
| Voltage Compatibility | 110V/230V/380V three voltages | Single voltage output |
| Portability | 42kg + 0.48m³ volume | 55kg + 0.68m³ volume |
| Customized Services | Supports (voltage/power/interface) | None
Market Advantage
Vertical Supply Chain Cost Control: The integrated model of industry and trade combines the R&D - production - export chain, achieving price advantages and a 48-hour rapid quotation response.
Global Certification: CE/ISO dual certification, compliant with energy efficiency standards in Europe, Asia, Southeast Asia, and Africa.
Deep Customization Capability: Supports OEM/ODM, providing voltage fine-tuning, power segment control, and special interface expansion, among other exclusive services.
Application Scenarios
▶ Outdoor Life: RV travel, camping power supply, outdoor weddings
▶ Small and Micro Businesses: Mobile coffee carts, night market stalls, pop-up stores
▶ Professional Operations: Photography lighting teams, garden tools, small welding equipment
▶ Emergency Disaster Prevention: Home backup power supply, post-disaster rescue communication support
▶ Off-Grid Power Supply: Island guesthouses, remote scientific research base stations
