WP-100DE
HuaHe
Product Overview
The WP-100DE is a high-performance 4-inch diesel water pump designed for agricultural irrigation, construction site drainage, municipal emergencies, and more. Powered by the reliable HH178F diesel engine, it delivers a maximum lift of 29m, suction height of 8m, and a rated flow of 55m³/h. Compact and easy to move, it is the ideal solution for efficient water transfer.
FAQ
Q1: What applications is this pump suitable for?
A1: It is ideal for farm irrigation, construction site drainage, municipal emergency water removal, and reservoir water transfer.
Q2: Is professional training required to operate it?
A2: No, it features simple one-start operation and comes with a user manual for quick setup.
Q3: Is maintenance complicated?
A3: Basic maintenance includes cleaning the filter and checking engine oil—simple and user-friendly.
Q4: Can it run continuously for long periods?
A4: Yes, the 12L fuel tank allows for several hours of continuous operation under full load.

Product Overview
The WP-100DE is a high-performance 4-inch diesel water pump designed for agricultural irrigation, construction site drainage, municipal emergencies, and more. Powered by the reliable HH178F diesel engine, it delivers a maximum lift of 29m, suction height of 8m, and a rated flow of 55m³/h. Compact and easy to move, it is the ideal solution for efficient water transfer.
FAQ
Q1: What applications is this pump suitable for?
A1: It is ideal for farm irrigation, construction site drainage, municipal emergency water removal, and reservoir water transfer.
Q2: Is professional training required to operate it?
A2: No, it features simple one-start operation and comes with a user manual for quick setup.
Q3: Is maintenance complicated?
A3: Basic maintenance includes cleaning the filter and checking engine oil—simple and user-friendly.
Q4: Can it run continuously for long periods?
A4: Yes, the 12L fuel tank allows for several hours of continuous operation under full load.

| Model | WP-100DE |
| Connect system | 100mm |
| Lift Height | 29m |
| Suction height | 8m |
| Rated flow | 55m³/h |
| Engine | HH178F |
| Displacement | 296CC |
| Rated speed | 3600RPM |
| Output power | 4.0KW |
| Fuel tank volume | 12L |
| Weight | 49KG |
| Dimension(L*W*H) | 560*505*720mm |
| Model | WP-100DE |
| Connect system | 100mm |
| Lift Height | 29m |
| Suction height | 8m |
| Rated flow | 55m³/h |
| Engine | HH178F |
| Displacement | 296CC |
| Rated speed | 3600RPM |
| Output power | 4.0KW |
| Fuel tank volume | 12L |
| Weight | 49KG |
| Dimension(L*W*H) | 560*505*720mm |
Features & Highlights
· Powerful Engine: Equipped with HH178F diesel engine, 296cc displacement, and 4.0kW output for reliable performance
· High Efficiency: Rated flow of 55m³/h, max lift of 29m, and 8m suction height for wide coverage
· Portable Design: Weighs only 49kg with compact dimensions (560×505×720mm) for easy transport and storage
· Long Operation: 12L large fuel tank supports extended continuous use
· Durable Build: Robust construction ensures longevity even in harsh environments
Competitive Advantages
· Superior lift (29m) and suction (8m) compared to similar 4-inch pumps, suitable for complex terrains
· Low fuel consumption and noise, stable operation at 3600 RPM
· Lighter and more compact for easier deployment and mobility
Pain Point Solutions
Problem1: Traditional pumps lack sufficient lift for high or distant water transfer
Solution1: WP-100DE offers 29m high lift, ideal for elevated or remote water delivery
Problem2: High fuel consumption increases operating costs
Solution2: Optimized fuel system with 12L tank ensures economical and long-lasting operation
Problem3: Heavy and difficult to move
Solution3 Lightweight design (49kg) with portable structure for easy handling
Features & Highlights
· Powerful Engine: Equipped with HH178F diesel engine, 296cc displacement, and 4.0kW output for reliable performance
· High Efficiency: Rated flow of 55m³/h, max lift of 29m, and 8m suction height for wide coverage
· Portable Design: Weighs only 49kg with compact dimensions (560×505×720mm) for easy transport and storage
· Long Operation: 12L large fuel tank supports extended continuous use
· Durable Build: Robust construction ensures longevity even in harsh environments
Competitive Advantages
· Superior lift (29m) and suction (8m) compared to similar 4-inch pumps, suitable for complex terrains
· Low fuel consumption and noise, stable operation at 3600 RPM
· Lighter and more compact for easier deployment and mobility
Pain Point Solutions
Problem1: Traditional pumps lack sufficient lift for high or distant water transfer
Solution1: WP-100DE offers 29m high lift, ideal for elevated or remote water delivery
Problem2: High fuel consumption increases operating costs
Solution2: Optimized fuel system with 12L tank ensures economical and long-lasting operation
Problem3: Heavy and difficult to move
Solution3 Lightweight design (49kg) with portable structure for easy handling
