WP-30A
HuaHe
| Model | WP-30 |
| Connect system | 80mm |
| Lift Height | 28m |
| Suction height | 7m |
| Rated flow | 60m³/h |
| Engine | HH168F |
| Displacement | 196CC |
| Rated speed | 3600RPM |
| Output power | 3.8KW |
| Fuel tank volume | 3.6L |
| Weight | 22.5KG |
| Dimension(L*W*H) | 505*380*415mm |
| Fuel | Gasoline |
Introduction:
The Huahe brand 3 inch gasoline pump is a powerful and efficient product designed for various pumping applications. Here is a brief introduction to its specifications:
1. Engine: The pump is equipped with a high-quality gasoline engine that provides reliable power for efficient pumping. The engine is designed to deliver optimal performance and is known for its durability and fuel efficiency.
2. Pump Size: The pump has a three-inch inlet and outlet size, allowing for efficient flow of liquids. This size is suitable for handling a wide range of fluids, including water, chemicals, and other non-corrosive liquids.
3. Suction Capacity: The pump has an impressive suction capacity, enabling it to draw liquids from a depth of up to a specified measurement (28 m ).
4. Lift Capacity: With a strong lift capacity, the pump can effectively deliver liquids to a specified height (7 m). This makes it suitable for applications that require pumping liquids to elevated locations or over long distances.
5. Flow Rate: The pump offers a high flow rate, indicating the volume of liquid it can pump in a given time. The flow rate is typically measured in cubic meters per hour or gallons per minute. (60 cubic meters per hour)
6.Output Power: The pump has an output power of 3.8 kilowatts, providing sufficient power to drive the pump's operation and ensure effective pumping performance.
7. Construction and Durability: The Huahe brand pump is built with robust materials to ensure durability and long-lasting performance. It is designed to withstand tough operating conditions, making it suitable for demanding applications.
8. Portability and Ease of Use: The pump is designed to be portable and user-friendly. It is equipped with handles or other features that make it easy to transport and maneuver. It also incorporates user-friendly controls and interfaces for convenient operation.
9. Applications: The Huahe brand three-inch gasoline pump combines its suction and lift capacities with a high flow rate and output power to deliver reliable and efficient pumping performance. It is suitable for various applications, including agricultural irrigation, construction sites, drainage, and water transfer tasks.The Huahe brand three-inch gasoline pump is suitable for various applications, including agricultural irrigation, construction sites, flood control, drainage, and water transfer tasks. It can efficiently handle both clean water and liquids with small solids or debris.
Advantage
1. Easier to start.
2.Overload protection for safe running.
3.Solid Muffler to reduce the noise.
4.Full protection for easy transportation and carry.
5.Compact, light and portable power source for Agriculture .
6.Economical, low fuel consumption for continuous stable running.
7.100% testing with loaded before packing.
8.With CE,GS,ROHS,ISO9001,TUV,SONCAP certification.
9.12 months warranty for long sevices life.
10.Reasonable price with higher quality.
In summary, the Huahe brand three-inch gasoline pump offers a powerful and reliable pumping solution. With its robust construction, efficient engine, impressive suction and lift capacities, high flow rate, and user-friendly design, it is well-suited for a wide range of applications in different industries.
