10 Ton Efficient 4-wheel Lithium Battery Counterweight Forklift

Product Specification

Huahe lithium electric forklift also has 1.5 tons,1.8 tons2.0 tons, 2.5 tons,  3.0 tons, 3.5 tons, 3.8 tons and of products for your choiceIf you feel that this lithium electric forklift meets your procurement needs or want other types of forklifts such as  LPG forklifts and diesel forklifts, you can contact us, we provide 24-hour online consultation service, welcome your questions at any time.

Product Key Features

1. High-Performance LiFePO₄ Battery – Long Life, Fast Charge, Maintenance-Free

The HFE100 is powered by Huahe’s self-developed LiFePO₄ battery system, delivering over 3,000 charge cycles and a service life of 5-8 years – 2-3 times longer than traditional lead‑acid batteries. Fast charging completes a full charge in just 1-2 hours. Opportunity charging during breaks supports near 24/7 continuous operation without requiring spare batteries. Completely maintenance‑free – no water topping, no equalizing charge – significantly reducing daily labor and time costs.

2. Smart Interactive Dashboard & Fleet Management System – Data-Driven Efficiency

The intelligent dashboard displays real‑time data including battery level, remaining runtime estimate, operating hours, speed, fault codes, and maintenance alerts, keeping the operator fully informed. The integrated GPS/BeiDou fleet management system allows managers to view vehicle location, utilization, operating hours, and remote diagnostics via a web portal or mobile app. This helps optimize dispatching, prevent theft/misuse, and improve Overall Equipment Effectiveness (OEE).

3. Exceptional Performance & Heavy-Duty Capability

Rated load capacity of 10,000 kg, maximum lift height of 3,000 mm, and free lift of 190 mm. Full-load travel speed of 18 km/h and gradeability of 16% (approx. 9°) allow it to handle ramps, outdoor yards, and other demanding conditions. The minimum turning radius is only 3,960 mm – excellent for a 10‑ton class forklift – ensuring agile maneuverability in tight indoor and outdoor spaces.

4. Multiple Electrical Safety Protections – Prevent Failures at the Source

Equipped with Huahe’s self‑developed AC+DC drive controller, the system includes overload protection, short‑circuit protection, over‑temperature protection, and under‑voltage protection. When an anomaly is detected, the system automatically limits speed or shuts down safely, preventing unplanned downtime. The control system has passed rigorous high/low temperature cycling and vibration tests, ensuring stable operation from -20°C to 55°C.

5. Eco-Friendly & Ergonomic Design – Zero Emission, Low Noise, Compact

Zero tailpipe emissions and significantly lower noise than internal combustion forklifts – compliant with the strictest environmental standards. The ergonomic operator compartment reduces fatigue, while the compact chassis and small turning radius provide excellent agility in narrow warehouses and even inside shipping containers.

Comparative Advantages

Pain Point Solutions

Pain Point 1: Frequent breakdowns and long unplanned downtime

Traditional forklifts often suffer from overheating or overload under heavy-duty conditions, leading to production interruptions.

Solution: The HFE100 features the Huahe AC+DC intelligent controller with built‑in overload, short‑circuit, over‑temperature, and under‑voltage protection. The system continuously monitors critical parameters and issues warnings or limits speed when anomalies are detected – preventing failures before they cause downtime.

Pain Point 2: Inefficient fleet management and low equipment utilization

Without real‑time visibility of each forklift’s location, operating status, and utilization, fleet dispatching is based on experience, leading to idle equipment or misuse.

Solution: The standard fleet management system uses GPS/BeiDou positioning and big‑data analytics. Managers can view real‑time location, travel history, operating hours, charge/discharge records, and maintenance status via a web portal or app. This data supports scientific dispatching and performance evaluation, improving OEE by 15-25%.

Pain Point 3: Increasingly strict environmental regulations

Steel mills, ports, and logistics centers face tightening limits on emissions and noise. Traditional internal combustion and lead‑acid forklifts struggle to meet compliance requirements.

Solution: The HFE100 is zero‑emission, with no exhaust fumes and much lower noise than ICE equipment. The LiFePO₄ battery contains no heavy metals and poses no acid spill risk, fully meeting domestic and export market environmental standards – helping customers avoid penalties and accelerate green factory initiatives.

Pain Point 4: High operating costs and unpredictable TCO

Lead‑acid batteries need replacement every 2-3 years, daily watering, and long charging times. ICE forklifts suffer from fuel price volatility and expensive engine maintenance.

Solution: The HFE100’s LiFePO₄ battery lasts 5 years with zero daily maintenance. Fast charging in 1-2 hours supports full‑shift operation. Over a 5‑year period, TCO is 30-40% lower than lead‑acid and over 50% lower than internal combustion forklifts .

FAQ

Q1: How long does the battery last on this 10‑ton lithium forklift?

Under normal use, the LiFePO₄ battery provides over 3,000 charge cycles and a service life of 5-8 years – 2-3 times longer than conventional lead‑acid batteries. The battery can still be used normally until capacity degrades to 80%, and replacement is not required for the entire pack at once.

Q2: How long does it take to charge? Can I charge it intermittently?

A full charge takes only 1-2 hours. The lithium battery supports opportunity charging – you can charge during lunch breaks or between handling tasks without needing to fully discharge it first, unlike lead‑acid batteries. This enables near 24/7 continuous operation.

Q3: What information does the smart dashboard show?

The dashboard displays real‑time data: battery level, estimated remaining runtime, operating hours, travel speed, fault codes, and maintenance alerts. It also records operator data for management analysis.

Q4: What actual benefits does the fleet management system bring?

Managers can view real‑time location, historical travel routes, operating hours, charge/discharge records, and fault alerts via a web portal or mobile app. This data helps optimize vehicle scheduling, prevent theft/misuse, plan preventive maintenance, and provide objective performance metrics for operators.

Q5: Is this forklift suitable for outdoor use?

Yes. The HFE100 features weather‑protected drive motors and controllers, plus pneumatic tires. With 16% gradeability (approx. 9°), it can handle port yards, factory ramps, and outdoor storage areas. Avoid operating in water deeper than half the tire height for extended periods.

Q6: What are the charging infrastructure requirements?

A compatible intelligent charger (Huahe original recommended) is required, with three‑phase 380V/50Hz power input. The charger includes automatic shut‑off and temperature protection for safe charging.

Q7: What is the warranty and after‑sales support?

Huahe Heavy Industry provides a 1‑year or 2,000‑hour warranty on the whole forklift (whichever comes first), and a 5‑year or 10,000‑hour warranty on the LiFePO₄ battery. Service centers are available in major cities, with 7×24 remote support and 48‑hour on‑site response. Please contact Huahe official sales channels for details.
